M4250-26G4F-PoE++ (GSM4230UP)
24x1G Ultra90 PoE++, 2x1G RJ45 and 4xSFP Layer 3 Managed Pro AV Line Switch
Mô tả sản phẩm
. CPU/RAM/FLASH: Quad-Core Cortex-A57 ARMv8 1.8Ghz (64-bit)/2GB RAM/256MB Flash
. 1-port 1G Out-of-band RJ45 + 24 x 10/100/1000 Ultra90 PoE++ RJ45 + 4 x 1G SFP
. PoE standard: 802.3af (15.4W), 802.3at (30W) và 802.3bt (60W, 75W and 90W)
. Stacking: Không hỗ trợ
. Bandwidth/Throughput: 60 Gbps/44.64 Mpps
. MAC/ARP Table/IP Multicast Routing Entries/IGMP: 16K/4K/512 IPv4, 128 IPv6/2K IPv4, 2K IPv6
. VLAN/ACLs/Packet Buffer/Jumbo Frames: 4K/100/16Mb/Up to 12K packet size
. Application Route Scaling: Static: 64 v4/64 v6, RIP: 32v4
. Layer-3: IPv4/IPv6 Static Routing, IPv4: RIP; IPv4/IPv6: PIM-SM, PIM-DM, SSM
. Audio profiles: Dante, Q-SYS, AES67 và AVB
* AVB license mua riêng theo từng switch model
. Video profiles: NVX, SVSI, Q-SYS, NDI và Dante, …
. PoE Power Budget (Watts): 1 PSU used – 720W, 2 PSU used- 1440W
. Fan/PSU/Form Factor: Side-to-side airflow, 2 x Fixed Internal (C14 inlet) On/Off switch, 1U Rackmount
